Turing MF640 Uncooled Infrared Module (Imaging)

China Moneypro

The Turing MF640 uncooled infrared module has a built-in high-sensitivity VOx infrared detector, providing a consistently high-performance kernel, ultimate image algorithms, and technology of lens control, bringing a new experience for long-distance monitoring. The product can be widely used in application scenarios such as perimeter security, high-altitude observation, forest fire prevention, and water area monitoring.

Feature

All-Weather, All-Scenario Ultra-Fast Focusing

By optimizing the lens control technology and employing a series of continuous zoom lenses, this product achieves full focus in all temperature ranges
Automatic focusing algorithms are deeply optimized to achieve ultra-fast focusing in 1 second, improving the focusing speed in general and weak target scenarios. The image is clear throughout the process in application scenarios like target tracking and linkage magnification.

Providing Sharp Infrared Images

The module upgrades the image algorithm to the new generation and optimizes the image for special scenarios such as forests, sea, sky, and rainy and foggy weather, providing customers with clear and sharp infrared images.

Providing Optimized Lens

It supports athermalized prime lenses, prime electric focusing lenses, and continuous zoom lenses.
It can realize electric focus, continuous zoom, automatic focus, and defocusing compensation functions, etc.

Multiple Interfaces, Easy for Secondary Development

It provides interfaces, BT.601, BT.1120, and other video output interfaces.
Expandable SDI, USB, Cameralink, and HDMI interfaces.
Multiple SDK are provided, which are simple and easy to use, shortening the development cycle, improving efficiency, and reducing secondary development costs.

Specification

Category	Parameter	Specification
Performance Indicators	Detector Type	Uncooled VOx infrared detector
	Resolution	640 × 512
	Detector Frame Rate	25 Hz
	Pixel Pitch	12 μm
	Spectral Band	8~14 μm
	NETD	≤40 mK at 25℃, F#1.0
Image Adjustment	Palette	Support (20 types)
	Digital Zoom	1.0~8.0× continuous zoom (step size: 0.1)
	Image Processing	Non-uniformity correction / Brightness & contrast adjustment / Temporal filtering / Spatial filtering noise reduction / Digital detail enhancement / Style adjustment
	Mirroring	Horizontal / Vertical / Diagonal
Network Function	Network Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, IGMP, SMTP, NTP, QoS, etc.
	Platform Access	Modbus TCP, MQTT protocols, ONVIF, GB28181, SDK
	Simultaneous Previewed Videos	Up to 8 channels
	User Management	Up to 20 users, 3 levels: administrator, operator, user
	Browser	Google Chrome, Firefox, Edge, etc.
Intelligent Functions	Intelligent Video	Supported
	Intelligent Alarm	Detects abnormalities, including network cable disconnections, IP conflicts, memory errors, unauthorized access, and burn warnings, and triggers alarms
	Intelligent Detection	Supports regional intrusion, tripwire intrusion, passenger and vehicle recognition
	Alarm Linkage	Video recording / Image capture (thermal image supported) / Email / Linked PTZ / Alarm output
Lens	Lens Type	Athermalized / Motorized fixed-focus / Continuous zoom
	Focus Mode	Manual / Automatic
	Electric Focusing	Supported
	Electric Zooming	Supported
Digital	Power Supply Range	5-24V DC (Recommended: 12V DC)
	Typical Power Consumption @25°C	<1.5 W
	Digital Video	LVCMOS / BT.601 / BT.1120
	Communication Interface	RS-232 / UART
Network Type	Power Supply Range	9-15V DC (Recommended: 12V DC)
	Typical Power Consumption @25°C	<2.0 W
	Communication Interface	One RJ45 10M/100M adaptive Ethernet port, one RS-485, one UART
	Alarm Interface	One input, one output
	Audio Interface	One input, one output
Interface	Analog Video	1-channel PAL system
Environment Adaptability	Operating Temperature	-40℃ ~ +70℃
	Storage Temperature	-45℃ ~ +85℃
	Humidity	5~95%, non-condensing
	Product Certification	RoHS2.0
PTZ Function	Fire Warning	Supports fire point detection
Thermal Imaging	Measurement Range	-20℃ ~ +150℃, 0℃ ~ +650℃
	Measurement Accuracy	±2°C or ±2% of reading (whichever is greater) @ ambient temperature -20°C ~ +60°C
