Photon MM615L Medium-Wave Cooled Infrared Module

China Moneypro

The Photon MM615 medium-wave cooled infrared module is provided with the high-performance HgCdTe cooled infrared FPA detector, and carried with the self-developed image processing algorithm.
It has the NETD as low as 15mK.
It supports multiple digital video interfaces, is suitable for multiple focus and continuous zoom lenses, and is widely applied in sighting distance enhancement, dynamic loading, and other scenarios.
It provides an SDK, which is simple and easy to use, reducing secondary development costs.

Feature

1. Delicate Images with High Sensitivity

The NETD is rated at just 15mK, which satisfies the demands for detecting small targets over long distances.

2. Self-Developed Algorithm for Intelligent Imaging

Equipped with a newly self-developed imaging algorithm, it enables a wide dynamic range and adaptive integration timing, delivering optimal image quality tailored to various scenarios.

3. Higher Frame Rate for Timely Capture

The maximum resolution reaches 640 × 512, and the frame rate can go up to 50 Hz, satisfying the needs for capturing large-scale dynamic targets.

Specification

Performance Indicators
Detector Type	HgCdTe cooled infrared detector
Resolution	640 512
Frame Rate	50 Hz/30 Hz
F#	F4.0/F5.5
Pixel Pitch	15 m
Spectral Band	3.7 0.2 m 4.8 0.2 m
NETD	15mK@25
Detector Defective Pixel Rate	0.5%
Cooling Time@25 C	7min
Image Adjustment
Brightness/Contrast Adjustment	Manual/Auto
Polarity	Black-hot/White-hot (white-hot by default)
Reticle	Display/Blank/Move
Image Processing	Non-uniformity correction, digital filter noise reduction, digital detail enhancement
Mirroring	Horizontal/Vertical/Diagonal
Power Supply
Power Consumption (Typical, @25 C)	Stable power consumption 10W, peak power;consumption 25W
Interface
Analog Video	PAL
Digital Video	Cameralink/SDI/Ethernet
Serial Communication Interface	RS422(default baud rate: 115200)
Physical Characteristics
Dimensions (Without lens)	480g (without isolation)
Weight (Without lens)	120 88 57mm ( 1) (without isolation)
Environment Adaptability
Operating Temperature	-40+60
Storage Temperature	-45+65
Temperature Shock	-45 ~+65棨 5 /min
Random Vibration	4.2g
Shock	Final peak sawtooth wave, 40g, 11ms (18 times in three axes and six directions in total)
MTTF	6000h
Storage Life	10 years
Power and Interface
Typical Power Consumption at 25 C	Stable power consumption 10W, peak power consumption 25W
More
Power Supply Range (With isolation)	/
Power Supply Range (Without isolation)	11~13V DC (typical 12V)
External Synchronization	Internal synchronization (default)/external synchronization/adaptive synchronization mode
