MTE365 Dual-Spectrum Explosion-Proof Bullet Camera

Feature

Adopting the latest 12μm uncooled infrared detectors, integrated with advanced infrared imaging algorithms for better image quality.

All-weather, 24/7 security monitoring with dual thermal&visible light imaging.

Certified with dual explosion-proof ratings for dust and gas: Ex db IIc T6 Gb and Ex tb IIc T80°C D.

Measurement range from -20℃ to 550℃, accuracy ±2℃ or 2%.

Features an integrated intelligent fire detection algorithm for efficient and accurate monitoring.

Support tripwire/intrusion detection, as well as intelligent detection of fire point.

Thermal Module
Detector Type	VOx, uncooled FPA detectors
Spectral Range	8~14μm
NETD	≤40mK@25℃,F#1.0
Resolution	640×512
Pixel Pitch	12μm
Focal Length	9.1mm / 13mm
Optical Module
Sensor	5MP 1/2.8″ Progressive Scan CMOS
Resolution	2560×1920
IR distance	50m
PTZ
Pan	360° continuous rotation
Tilt	-90°~+90°
Temperature Measurement
Temperature Measurement	Support 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire Detection	Support
VCA	Support Line Crossing&Intrusion detection
2-Way Audio	Support
Linkage Action	Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power	AC100~260V
Network	1 RJ45 10M / 100M self-adaptive Ethernet port
Audio	1 in/1 out
Alarm	2 in/2 out
Storage	Micro SD memory（maximum 256G）
Reset	Support
Serial Port	1 channel RS485, can support Pelco protocol
General
Work Environment	-40℃~+70℃；<95%RH
Protection	IP68
Power Consumption	≤8W
Dimenstion(mm)	275.5×186×203
