MFC460A Observation Thermal Bullet Camera

China Moneypro

MFC4A thermal bullet camera equipped a 640×512, 12 μm pixel pitch thermal detector with a focal length up to 75mm.
It supports tripwire/intrusion detection.
It can be used for perimeter protection in critical facilities.
Support TPM technology and meeting the FIPS 140-3 Level 3 standard.

Feature

12μm Uncooled Infrared Detector

Leveraging state-of-the-art 12μm uncooled infrared detectors alongside sophisticated infrared imaging algorithms, this solution delivers significantly enhanced image quality.

Intelligent Video Analysis

Supports perimeter breach alerts and intrusion identification, along with smart detection of fire sources.

Long-Range Detection

This system is compatible with 35mm, 55mm, and 75mm fixed-focus infrared lenses, enabling effective long-range detection.

Platform Integration

Supports ONVIF, offers SDK and demo for development, and includes NVR and VMS software for application deployment.

Specification

Thermal Module
Detector Type	VOx, uncooled FPA detectors
Spectral Range	8~14μm
NETD	≤40mK(@25°C, F#1.0, 25 Hz)
Resolution	640×512
Pixel Pitch	12μm
Focal Length	35mm/55mm
Smart Function
Fire Detection	Support
VCA	Support Line Crossing & Intrusion detection
2-Way Audio	Support
Linkage Action	Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power	DC 12V±25%/POE(802.3at)
Network	1 RJ45 10M / 100M self-adaptive Ethernet port
Audio	1 in/1 out
Storage	Micro SD memory（maximum 256G）
Reset	Support
Serial Port	1 channel RS485, can support Pelco protocol
Analog	1 BNC
General
Work Environment	-40℃~+70℃；<95%RH
Protection	IP66
Certification	CE,ROHS,CE-EMC Test Report, FIPS 140-3 Level 3
Power Consumption	≤4W
Dimenstion(mm)	334.7×121.5×104.4
Weight	≤1.5kg
