Turing MF1920 HD Uncooled Infrared Module

China Moneypro

The brand-new Turing MF1920 is equipped with the world s first 8 m 1920 1080 HD infrared detector, and the NETD as low as 30mK. Combined with our self-developed e cient large-array image algorithm, the device provides customers with more subtle, sharper, and clearer thermal images. It supports multiple lenses and applies the lens control technology, offering a comprehensive observation solution within a range of 1m~15000m in fields such as perimeter security, high-altitude observation, oil field monitoring, forest fire prevention and scientific research in universities

Feature

High-pixel, High-integration

2 megapixels, 1920 1080 HD resolution, large FOV, providing an immersive experience.
Video output interface options including network interfaces, LVCMOS, BT.1120 and MIPI, with extensions for interfaces such as SDI, USB, Camera Link, and HDMI.
Gigabit network interface, multiple SDKs, facilitating customers to launch simple, ecient integrated secondary development at a low cost.

Quick Focus, Quick Recognition

New lens control technology for 1s automatic focus, full focus in all temperature ranges.
Quick recognition algorithm within 50ms.

Multi-lens Adaptability, Multi-scenario Application

Multiple athermalized prime lenses with a max FOV of 82 , prime electric focusing lenses, and continuous zoom lenses.
8 m infrared detector for further recognition in fields of perimeter security, high-altitude observation, oil field monitoring.
Rich image style options for ideal image effect in scenarios such as perimeter monitoring and forest fire prevention.

Stable Output, Steady Images

Stable and reliable 30Hz data stream output to monitor targets in each frame.
Standard electronic anti-shake technology to provide stable images even in strong wind or at high altitudes.

Specification

Category	Parameter	Specification
Performance Indicators	Detector Type	Uncooled VOx infrared detector
	Resolution	1920 × 1080
	Detector Frame Rate	30 Hz
	Pixel Pitch	8 μm
	Spectral Band	8~14 μm
	NETD	≤30 mK @ 25°C, F#1.0
	Electronic Anti-shake	Supported
	Fire Alarm	Supported
	High Light Protection	Supported
Image Adjustment	Palette	Support (20 types)
	Digital Zoom	1.0~8.0× continuous zoom (step size: 0.1), supporting zooming in any area
	Image Processing	Filtering noise reduction / Digital detail enhancement / Image style switch / Non-uniformity correction / Brightness & contrast adjustment / Temporal filtering noise reduction / Spatial filtering
	Mirroring	Horizontal / Vertical / Diagonal
Network Function	Network Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, IGMP, SMTP, NTP, QoS, etc.
	Platform Access	ONVIF, GB28181, SDK
	Browser	Chrome, Edge, Firefox, etc., multiple languages
Intelligent Functions	Intelligent Alarm	Abnormality detection and linkage alarm for network cable disconnection, IP conflict, full memory, memory error, illegal access
	Intelligent Detection	Tripwire, regional intrusion, target tracking, and other intelligent video analysis functions
	Alarm Linkage	Video recording / Image capture / Email / Linked PTZ / Alarm output
	Intelligent Video Taking	Supported
Lens	Lens Type	Athermalized / Motorized fixed-focus / Continuous zoom
	Focus Mode	Manual / Automatic (focus time ≤1s near clear points)
	Electric Focusing	Supported
	Electric Zooming	Supported
Digital	Power Supply Range	5-24V DC (12V DC recommended)
	Typical Power Consumption @25°C	≤3.8 W
	Digital Video	LVCMOS / BT.1120 / MIPI, with extensions for SDI, USB, CameraLink, HDMI
	Communication Interface	RS-232 / RS-485
	Weight	165 ±5 g (without lens)
	Dimensions	55 × 55 mm
Network Type	Power Supply Range	12V DC ±10%
	Typical Power Consumption @25°C	≤6.5 W
	Communication Interface	One 10M/100M/1000M adaptive Ethernet port, one RS-485
	Alarm Interface	1 input, 1 output
	Audio Interface	1 input, 1 output
	Weight	240 ±10 g (without lens)
	Dimensions	55 × 55 × 53 mm
Environment Adaptability	Operating Temperature	-40°C ~ +70°C
	Storage Temperature	-45°C ~ +85°C
	Humidity	5~95%, non-condensing
	Product Certification	RoHS2.0
