Photon MH615 Medium-Wave HOT Cooled Infrared Module

China Moneypro

The Photon MH615 medium-wave HOT cooled infrared module is provided with the high-performance T2SL cooled infrared FPA detector, is designed with SWaP, and is carried with the self-developed image processing algorithm.
It works flexibly and reliably and plots quickly. It supports multiple digital video interfaces, is suitable for multiple focus and continuous zoom lenses, and is widely applied in the mini pod, handheld, and other scenarios.
It provides an SDK, which is simple and easy to use, reducing secondary development costs.

Feature

1 Industry-Leading SWaP Design
With compact dimensions of just 76.5 × 69.2 × 46.6 mm, a minimum weight of 359 g, and power consumption as low as 6 W, this design is well suited for space-constrained, miniaturized applications.

2 Delicate Images with High Sensitivity
The NETD is rated at just 20mK, which satisfies the needs for detecting small targets over long distances.

3 Self-Developed Algorithm for Intelligent Imaging
Equipped with a newly self-developed imaging algorithm, it enables a wide dynamic range and adaptive integration timing, delivering optimal image quality tailored to various scenes.

4 Fast Imaging for Timely Capture
Featuring the next-generation T2SL detector, this system delivers a maximum resolution of 640 × 512, supports frame rates up to 50 Hz, and achieves a cooling time as short as 2.5 minutes—making it well-suited for large-scale dynamic target acquisition.

5 High Reliability and Durability
The mean time to failure (MTTF) reaches up to 20,000 hours, with an operating temperature span of -40°C to +70°C, guaranteeing dependable operation under harsh conditions like those found in polar areas or hot deserts.

Specification

Performance Indicators
Detector Type	T2SL Cooled Infrared FPA
Resolution	640 512
Detector Frame Rate	50 Hz/30 Hz
Pixel Pitch	15 m
Spectral Band	3.7 4.8 m
NETD	20mK@F4.0 25 / 25mK@F5.5 25
Image Adjustment
Brightness/Contrast Adjustment	Manual/Auto
Polarity	Black-hot/White-hot (white-hot by default)
Palette	Multiple types support
Reticle	Display/Blank/Move
Image Processing	Non-uniformity correction, digital filter noise reduction, digital detail enhancement
Mirroring	Horizontal/Vertical/Diagonal
Power Supply
Power Supply Range (typical)	12 0.5V DC
Typical Power Consumption at 25 C Without Extension	Stable power consumption 6W, peak power consumption 12W@Cameralink/Stable power consumption 7W, peak power consumption 13W@SDl
Interface
Analog Video	PAL
Digital Video	Cameralink/SDI
Serial Communication Interface	RS422 (default baud rate:115200)
Synchronization Mode	Internal synchronization (default)/External synchronization/Adaptive synchronization mode
Physical Characteristics
Dimensions (Without lens)	76.5 69.2 46.6mm
Weight (Without lens)	364g@Cameralink/359g@SDI
Environment Adaptability
Operating Temperature	-40 C~ +70 C
Storage Temperature	-45 C~ +75 C
Random Vibration	4.16g
Shock	Final peak sawtooth wave, 40g, 11ms (18 times in three axes and six directions in total)
