MTB650P Thermal Imaging Attachment
China Moneypro
The TB Pro Series perfectly balances precision and portability. The magnesium alloy housing decreases weight while increasing precision. The weights are over 20% lighter than those of other similar products. It is also more compact than our previous clip-on. Meanwhile, a Full-HD AMOLED display is capable, a wider viewing angle, and richer color. It is the ideal partner for relax hunting
NETD20mK
AMOLED Display1920×1080
Detection Range2600m
EncapsulationIP68
12μm infrared detector
Equipped with a highly sensitive 12μm infrared sensor, the TB Pro Series achieves a NETD as low as 20mK. This advanced thermal detector enables precise identification of even the smallest temperature variations and differences.
50mm focal length
The TB Pro Series features an extended 50mm focal length, delivering a greater observation distance and finer image details compared to standard 25mm or 35mm lenses.
2600m ultra-long detection range
With an extended detection range of up to 2,600 meters, it enables ultra-long-distance target identification, allowing you to spot finer details and see further during outdoor activities.
High protective IP68
With IP68-rated dustproof and waterproof protection, plus 1000G/ms shock resistance, this device reliably supports outdoor observation, hunting, or rescue missions—even in rain, fog, or misty conditions.
Full-HD AMOLED display
The 0.39-inch AMOLED display features a full HD 1920×1080 resolution, delivering vivid colors and outstanding image clarity, which greatly improves viewing comfort.
Technical Parameters
| Sensor | ||||
|---|---|---|---|---|
| Type | Uncooled VOx Infrared Detector, 8 to 14μm | |||
| Resolution | 640×512@12μm | |||
| NETD | 20mK | |||
| Frame rate | 50Hz | |||
| Lens | ||||
|---|---|---|---|---|
| Objective lens | 50mm, F1.0 | |||
| Field of view | 8.8°×7.0° | |||
| FOV m@100m | 15×12 | |||
| Magnification | 1x | |||
| Detection range | 2600m/2800yd | |||
| Display | ||||
|---|---|---|---|---|
| Display type | 0.39” AMOLED 1920×1080 | |||
| Color palettes | White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia | |||
| Eyepiece | Eye relief: 20mm; Zoom: 6.8x | |||
| Hardware | ||||
|---|---|---|---|---|
| WIFI | 2.4G, 5G | |||
| Interface | USB Type-C (Power supply/USB2.0) | |||
| Others | Microphone, Bluetooth | |||
| System | ||||
|---|---|---|---|---|
| Recording function | Photo/Video (Audio recording included) | |||
| Memory capacity | 64GB | |||
| Power | ||||
|---|---|---|---|---|
| Battery type | 2 replaceable 18650 batteries | |||
| Operating time | 9 hours | |||
| Environmental | ||||
|---|---|---|---|---|
| Operating temp. | -20°C to 50°C / -4°F to +122°F | |||
| Shock | 1000G at 1ms half sine pulse (as per IEC60068-2-27) | |||
| Encapsulation | IP68 | |||
| Physical | ||||
|---|---|---|---|---|
| Weight (g/oz) | 582/20.53 | |||
| Size (mm/in) | 161×89×97/6.34×3.50×3.82 | |||
| Standard | A device, Battery charger, 18650 battery×2, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card | |||
| Optional | 18650 battery, Bluetooth remote control, Cover ring adapter | |||
