Cooled AD Module for Cooled Infrared Detector Integration
China Moneypro
The P series cooled AD modules provides power and control timing to drive the normal operation of the cooling infrared detector, and converts the analog output signal of the cooling infrared detector into a digital video stream output. Equipped with high performance signal processing circuit and standard cameralink interface that could output 16 bits raw data, P series cooled AD modules are applicable to all MCTu0026amp;
FEATURES
Accelerate development speed
With high-performance signal processing circuitsu003cbru003eDigitization of detector drive and analog signal
Easy to develop u0026amp; integrate
Cameralink interface output 16bit raw data, serial port controlu003cbru003eIntegrated structural design that has consistent dimension with detector
DESCRIPTION
The P series cooled AD modules provides power and control timing to drive the normal operation of the cooling infrared detector, and converts the analog output signal of the cooling infrared detector into a digital video stream output. Equipped with high performance signal processing circuit and standard cameralink interface that could output 16 bits raw data, P series cooled AD modules are applicable to all MCTu0026amp;T2SL cooled infrared detectors by China Moneypro.u003cbru003eThe P Series modules are available in various resolutions, including 320 256, 640 512, 1280 1024 pixels and pixel size of 30 m, 15 m, 12 m. This versatility allows users to select the resolution that best suits their specific needs, whether prioritizing detail or frame rate. Higher resolutions provide more detailed images, which can be critical in identifying specific thermal signatures.u003cbru003eWith P series cooled AD modules, it is easy for OEM customers to carry out fast acceptance test on cooled infrared detectors, start rapid secondary development and shorten their development period to complete products based on cooled infrared detectors.
APPLICATIONS
Remote Monitoring System
Search u0026amp; Tracking System
Electro-Optical Payload
SPECIFICATIONS
| Model | P1212Z | P615Z-RC2 | P615Z-RC1 | P330Z | P615C |
| Resolution | 1280 1024 | 640 512 | 320 256 | 640 512 | |
| Pixel Size | 12 m | 15 m | 30 m | 15 m | |
| Cryo Cooler | RC4 | RC2 | RC1 | RC2 | RC4 |
| Spectral Response | 3.7 m 0.2 m 4.8 m 0.2 m | 7.7 m 0.2 m~9.4 m 0.3 m | |||
| Cooling Time (25 ) | 6min | 6min | 5.5min | 6min | 5.5min |
| NETD (25 ) | 18mK | 17mK | 18mK | 9mK | 25mK |
| Frame Rate (Adjustable) | 1~100Hz | 1~120Hz | 1~50Hz | 1~200Hz | 1~160Hz |
| Working Mode | Snapshot; ITR/IWR Integration Mode; Windows Mode; Anti-blooming | Snapshot; ITR Integration Mode; Windows Mode; Anti-blooming | Snapshot; ITR & Interlace Binning Integration Mode; Windows Mode; Anti-blooming | ||
| Standard External Interface | QSH60 | ||||
| Digital Video | Cameralink: Output 16bit Raw Data | ||||
| External Sync | CC1: INT/Frame External Sync CC2: MC External Sync | ||||
| Communication | Cameralink Serial Port: TFG+/-, TC+/-; 9600bps | ||||
| Power Supply | Channel 1 (Imaging Panel): 5V Channel 1 (Cryocooler): 24V | Channel 1 (Imaging Panel): 5V Channel 1 (Cryocooler): 12V | Channel 1 (Imaging Panel): 5V Channel 1 (Cryocooler): 24V | ||
| Steady Power Consumption | 9W | 7W | 8W | 7W | 9W |
| Size (mm) | 148 58.5 71 | 142 58.5 71 | 122 88 59 | 142 58.5 71 | 148 58.5 71 |
| Weight | 660g | 640g | 380g | 640g | 640g |
| Working Temperature | -40 C ~ +60 C | ||||
