Turing MA640 Uncooled Infrared Module (Temperature Measurement)

China Moneypro

Turing MA640 uncooled infrared module is equipped with a 640 512 ceramic-packaged infrared detector. It can not only provide clear images and accurate temperature data but also be equipped with multiple serialized lenses and various kinds of user extension components for customers to select. It can be applied in many fields such as industrial and electrical temperature measurement, security, and machine vision.

Feature

Multiple Selections

Offer over 10 types of thermal-adapted lenses suitable for various applications at different distances.

Excellent Temperature Measurement Characteristics

Measurement capability spans -20°C to +550°C, enabling accurate and fast temperature evaluation.

Flexible Extension

This interface suite includes flexible options for USB, MIPI, DVP, LVDS, Camera Link, and analog video output. An SDK is provided to enable further customization and secondary development.

Specification

Category	Parameter	Specification
Performance Indicators	Detector Type	Uncooled VOx infrared detector
	Resolution	640 × 512
	Frame Rate	25 Hz
	Pixel Pitch	12 μm
	Spectral Band	8~14 μm
	NETD	≤50 mK at 25°C (≤40 mK optional)
Image Adjustment	Brightness/Contrast Adjustment	Manual / Automatic / Linear
	Polarity	Black-hot / White-hot
	Palette	Support
	Reticle	Display / Blank / Move
	Digital Zoom	1.0~4.0× continuous zoom (step size: 0.1)
	Image Processing	Tecless scenario-based non-uniformity correction / Digital filtering noise reduction / Digital detail enhancement
	Mirroring	Horizontal / Vertical / Diagonal
Power Supply	Power Supply Range (typical)	3.5~18 V DC (supported by user extension components), 4~5.5 V DC
	Typical Power Consumption @25°C (without extension)	<0.7 W
	Power Protection	Overvoltage, undervoltage, and reverse connection supported by user extension components
Interface	Digital Video	BT.656 / BT.1120 / 14-bit or 8-bit LVCMOS / LVDS
	Analog Video	1-channel PAL system
	Serial Communication Interface	UART (3.3 V) / RS-232
	Extension Components	MIPI / USB / Camera Link / Analog video / BT.656 / LVDS
Temperature Measurement Performance	Measurement Range	-20°C ~ +150°C, +100°C ~ +550°C (measurement series)
	Measurement Accuracy	±3°C or ±3% of reading (whichever is greater) at ambient temperature -20°C ~ +60°C ±2°C (optional)
	Measurement Tool	Secondary analysis of points, lines, and areas
Physical Characteristics	Dimensions (without lens and extension)	26 × 26 × 19.2 mm
	Weight (3.2 mm, without extension)	20 ±3 g
Environment Adaptability	Operating Temperature	-20°C ~ +60°C
	Storage Temperature	-45°C ~ +85°C
	Humidity	5~95%, non-condensing
	Vibration	6.06 g, random vibration, all axes
	Impact	80 g, 4 ms, final peak sawtooth wave, three axes, six directions
