MTE464T1 Dual-Spectrum Explosion-Proof PTZ Camera

China Moneypro

MTE464T1 dual-spectrum explosion-proof PTZ camera equipped with an HD visible light camera and a 640×512 thermal imaging camera.
MTE464T1 can rotate 360° to view all suroundings. 304 or 316 stainless steel is using for housing to let the camera operate in hazardous area.

Feature

12μm Uncooled Infrared Detector

Equipped with next-generation 12μm uncooled infrared sensors and enhanced by cutting-edge imaging algorithms, this solution delivers significantly improved infrared image clarity.

Dual-Spectrum Imaging

Round-the-clock surveillance in any climate, combining thermal and visible-light imaging for continuous day-and-night protection.

Dual Explosion-Proof Certification

Certified with both gas and dust explosion-proof approvals: Ex db IIc T6 Gb for gas environments and Ex tb IIc T80°C D for combustible dust.

Accurate Temperature Measurement

Measurement capability spans -20°C to 550°C, with a precision of ±2°C or 2% of reading.

Fire Point Detection

Equipped with a smart fire detection algorithm, it enables efficient and precise monitoring.

Intelligent Video Analysis

Supports tripwire and intrusion detection, along with intelligent fire point identification.

Specification

Thermal Module
Detector Type	VOx, uncooled FPA detectors
Spectral Range	8~14μm
NETD	≤40mK(@25°C, F#1.0, 25 Hz)
Resolution	640×512
Pixel Pitch	12μm
Focal Length	25mm
Optical Module
Sensor	4MP 1/1.8″ Progressive Scan CMOS
Resolution	2688×1520
Focal Length	6.5mm~130mm
PTZ
Pan	360° continuous rotation
Tilt	-90°~+90°
Temperature Measurement
Temperature Measurement	Support 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire Detection	Support
VCA	Support Line Crossing&Intrusion detection
2-Way Audio	Support
Linkage Action	Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power	AC85V~260V
Network	1 RJ45 10M / 100M self-adaptive Ethernet port
Alarm	1 in/1 out
Storage	Micro SD memory（maximum 256G）
Reset	Support
Serial Port	1 channel RS485, can support Pelco protocol
General
Work Environment	-40℃~+60℃；<90%RH
Protection	IP68
Power Consumption	≤100W
Dimenstion(mm)	436×296×406
Weight	27kg
