Cooled Medium-wave Infrared Camera Core
China Moneypro
The MAC series MWIR cooled infrared camera core delivers cutting-edge thermal imaging for demanding applications. Featuring advanced HgCdTe sensitive material, it offers exceptional clarity and sensitivity in the mid-wave infrared spectrum. Available in multiple resolutions from 320×256 to 1280×1024 with pixel sizes ranging from 30µm to 12µm, this system provides ultra-clear images with thermal sensitivity as low as 10mK NETD and 99.76% effective pixel rate. Embedded image processing algorithms enable superior performance in total darkness and adverse weather. Ideal for security, reconnaissance, remote monitoring, and electro-optical payloads, it detects minute temperature differences and recognizes threats at extended distances while delivering detailed target information at close range.
FEATURES
Ultra clear image
Various resolutions from 128 128 to 1280 1024u003cbru003eResolution up to 1280 1024 for wider FOV and longer distanceu003cbru003eDifferent pixel sizes: 30 m, 25 m, 15 m, 12 m, 10 m, 7 m
Outstanding performance
High thermal sensitivity, Typical NETD as low as 10mku003cbru003eGood uniformity, effective pixel rate 99.76%
DESCRIPTION
The MAC series MWIR (Medium Wave Infrared) cooled infrared camera cores are cutting-edge solutions designed for high-performance thermal imaging applications. Utilizing advanced HgCdTe (Mercury Cadmium Telluride) sensitive material, this infrared camera core delivers exceptional clarity and sensitivity in the mid-wave infrared spectrum, making it ideal for a variety of demanding environments.u003cbru003eThey are available with different resolutions of 320 256, 640 512, 1280 1024 and pixel sizes of 30 m, 25 m, 15 m, 12 m, and also different optical lens options. You can choose from a range of lens configurations to suit your specific needs.u003cbru003eVarious image processing algorithms are already embedded in the electronics to output clear infrared images in the total darkness or bad weather conditions. They can detect and recognize risks and threats at long distance while present more target details at short distance. With its superior thermal sensitivity, the MAC MWIR series can detect minute temperature differences, making it ideal for security applications, providing clear thermal images to detect and track potential threats.
APPLICATIONS
Handheld Reconnaissance System
Remote Monitoring System
Electro-Optical Payload
SPECIFICATIONS
| Model | MAC330Z | MAC615Z-RC2 | MAC615Z-RC1 | MAC625Z | MAC1212Z |
| Sensitive Material | MCT | ||||
| Resolution | 320 256 | 640 512 | 1280 1024 | ||
| Pixel Size | 30 m | 15 m | 25 m | 12 m | |
| Spectral Response | MW 3.7 0.2 m~4.8 0.2 m | ||||
| IR Detector NETD (@25 3 ) | 21mK | 20mK | 25mK | 15mK | 20mK |
| Frame Rate | 100/200Hz | 50/100Hz | 50Hz | ||
| Image Algorithm | DRC/DNS/3DNR/EE | ||||
| Analog Video | PAL/NTSC | ||||
| Digital Video | DVP/LVDS/USB2.0 | DVP | |||
| Communication | USB2.0/LV-TTL | ||||
| Steady Power Consumption(25 3 ) | 10W | 10W | 10W | 18W | 11W |
| Working Temperature | -40 ~+71 | ||||
| Size (mm) | 142 58.5 80 | 142 58.5 80 | 120 84 60 | 148 59 81 | 149 58.5 80 |
| Weight | 680g | 680g | 440g | 730g | 680g |
| Lens | Fixed Focus: 25mm/F2 Continuous Zoom: 30~240mm/F4 15-300mm/F4 45~450mm/F4 32~730mm/F4 | Fixed Focus: 25mm/F2Continuous Zoom:60~240mm/F4 15-300mm/F4 23~450mm/F4 | 40mm/F2 | Fixed Focus: 19mm/F2 Continuous Zoom:60~360mm/F437.5~750mm/F4 | |
| Extension Components | Digital Video:Cameralink/USB3.0/GigE/SDI/MIPI/Single-mode fiber/Multi-mode Fiber | Digital Video:Cameralink/USB3.0/GigE/HDMI/SDI/MIPI/Single-mode fiber/Multi-mode Fiber | |||
| Communication: RS422/CAN/USB3.0/GigE | |||||
