China Moneypro
Uncooled Infrared Camera Core with Lightweight Structure
China Moneypro
Experience cutting-edge thermal imaging with the FLEX Series, an uncooled LWIR camera core delivering 640×512 resolution and 12-micron pixel size for exceptional thermal clarity. Engineered for extreme portability, this ultra-compact module measures just 17.3mm x 17.3mm x 22.2mm and weighs only 13.5g, making it ideal for space-constrained applications. With ultra-low power consumption of just 0.5W and single power supply design, it maximizes battery life while simplifying system integration. Advanced image processing algorithms including NUC, 3DNR, DNS, DRC, and EE ensure crystal-clear images with accurate radiometry. Featuring precise regional, point, and isotherm temperature measurement capabilities, plus multi-platform SDK support for Windows, Android, and Linux. Perfect for UAV payloads, wearable devices, portable systems, forest fire detection, security monitoring, and predictive maintenance applications.
FEATURES
Compact u0026amp; lightweight design
Size: 17.3mm 17.3mm 22.2mm (with 9.1mm lens)u003cbru003eWeight: 13.5g (with 9.1mm lens u003cbru003eLow power consumption as low as 0.5W; single power supply for simpler system design
Clear image u0026amp; accurate radiometry
Brand new image process algorithm: NUC/3DNR/DNS/DRC/EEu003cbru003eSupport Windows/Android Linux SDKu003cbru003eSupport regional, point u0026amp; isotherm temperature measurement
DESCRIPTION
The FLEX series represents a next-generation uncooled long-wave infrared (LWIR) thermal camera core, designed for ultra-compact applications. It delivers a sharp 640×512 resolution with a 12 μm pixel pitch, producing highly detailed thermal imagery that significantly improves the detection and analysis of thermal targets. As a widely adopted 640×512 infrared solution in the current market, the FLEX series supports a broad range of uses.
This camera core integrates both high-quality thermal imaging and accurate temperature measurement functions. With multiple SDK options for seamless system integration and iterative upgrades, it meets the strict demands of compact system designs. Typical applications include forest fire detection, security surveillance, and more. Its advanced temperature measurement delivers precise thermal data for real-time monitoring and analysis of temperature changes in target environments—ideal for critical infrastructure checks or identifying potential fire hotspots in forests. The result is reliable, actionable intelligence.
Engineered with a strong focus on SWaP-C (size, weight, power, and cost), the FLEX series offers a dependable solution for infrared system integration in space-constrained scenarios. Pushing the limits of SWaP, the FLEX B612 model achieves a compact cross-section of just 17.3 mm × 17.3 mm and a total weight of only 13.7 grams—reaching the top tier for its specification class. The FLEX B612T variant further addresses spatial restrictions with reduced size and weight, extended battery life thanks to lower power consumption, and simplified integration across diverse applications. It opens new possibilities for compact and portable systems, making it the ideal choice for integrators with strict size and weight requirements.
The FLEX series uncooled infrared camera core is specifically developed for sectors such as predictive maintenance, photovoltaic inspection, environmental monitoring, scientific research, aerial photography, police investigations, disaster response and rescue, forest fire prevention, and urban safety management.
This camera core integrates both high-quality thermal imaging and accurate temperature measurement functions. With multiple SDK options for seamless system integration and iterative upgrades, it meets the strict demands of compact system designs. Typical applications include forest fire detection, security surveillance, and more. Its advanced temperature measurement delivers precise thermal data for real-time monitoring and analysis of temperature changes in target environments—ideal for critical infrastructure checks or identifying potential fire hotspots in forests. The result is reliable, actionable intelligence.
Engineered with a strong focus on SWaP-C (size, weight, power, and cost), the FLEX series offers a dependable solution for infrared system integration in space-constrained scenarios. Pushing the limits of SWaP, the FLEX B612 model achieves a compact cross-section of just 17.3 mm × 17.3 mm and a total weight of only 13.7 grams—reaching the top tier for its specification class. The FLEX B612T variant further addresses spatial restrictions with reduced size and weight, extended battery life thanks to lower power consumption, and simplified integration across diverse applications. It opens new possibilities for compact and portable systems, making it the ideal choice for integrators with strict size and weight requirements.
The FLEX series uncooled infrared camera core is specifically developed for sectors such as predictive maintenance, photovoltaic inspection, environmental monitoring, scientific research, aerial photography, police investigations, disaster response and rescue, forest fire prevention, and urban safety management.
APPLICATIONS
UAV Payloads
Wearable Devices
Portable Devices
