Turing ML384 Uncooled Infrared Module (Temperature Measurement)
China Moneypro
Turing ML384 uncooled infrared module has made further technical breakthroughs, redefining the new standard of weight, dimensions, and power consumption (SWaP3) in the infrared OEM module industry.
It meets professional needs in the fields of routine inspection, security, search and rescue, and industrial monitoring and provides excellent miniaturized high-resolution solutions for consumer products.
Feature
SWaP3 Design
- Its resolution is 384 288, dimension is 18 18mm, and weight is 3.5g, and it is a low-cost solution.
Excellent Performance
- It supports shutterless correction algorithm to provide a smooth and continuous user experience.
Multiple Selections
- Its FOV covers 10 ~90 , and it supports multiple interfaces, such as MIPI/USB/BT.656/analog video.
- Equipped with leading programmable modules, it features flexible architecture, multiple functions, and high customizability
Specification
| Category | Parameter | Specification |
|---|---|---|
| Performance Indicators | Detector Type | Uncooled VOx infrared detector |
| Resolution | 384 × 288 | |
| Detector Frame Rate | 25 Hz | |
| Pixel Pitch | 12 μm | |
| Spectral Band | 8~14 μm | |
| NETD | ≤50 mK at 25°C (≤40 mK optional) | |
| Image Adjustment | Brightness/Contrast Adjustment | Manual / Auto |
| Polarity | Black-hot / White-hot | |
| Palette | Multiple types support | |
| Reticle | Display / Blank / Move | |
| Image Processing | TEC-less temperature control algorithm / Digital filtering noise reduction / Digital detail enhancement | |
| Mirroring | Horizontal / Vertical / Diagonal | |
| Power Supply | Power Supply Range (typical) | 3.8~5.2V DC / 1.8V / 3.3V |
| Typical Power Consumption @25°C (without extension) | ≤0.25 W | |
| Interface | Digital Video | BT.656 / BT.1120 / LVCMOS |
| Serial Communication Interface | UART | |
| Extension Components | USB 2.0 / Analog video | |
| Temperature Measurement Performance | Measurement Range | -20°C ~ +550°C (up to +650°C customizable) |
| Measurement Accuracy | ±3°C or ±3% of reading (whichever is greater) at ambient temperature -20°C ~ +60°C ±2°C (optional) | |
| Measurement Tool | Secondary analysis of points, lines, and areas | |
| Physical Characteristics | Dimensions (Without lens and extension) | 18 × 18 mm |
| Weight (3.2mm, without extension) | 3.5 g | |
| Lens Model | 2.88 mm, 5.3 mm, 10.4 mm, 19 mm, expandable to 45 mm | |
| Environment Adaptability | Operating Temperature | -40°C ~ +80°C (-20°C ~ 60°C for measurement) |
| Storage Temperature | -45°C ~ +85°C | |
| Humidity | 5~95%, non-condensing | |
| Product Certification | RoHS |
Application Scenariosa
Fire Rescue
UAV Pod
Wearable Device
Security Monitoring
