MZT055TA Two-Axis Three-Light Turntable

The MZT055TA two-axis three-optic turret integrates an uncooled infrared thermal imager, a 20x continuous zoom visible-light camera, a laser rangefinder, a two-axis servo-stabilized platform, and an image tracker. With its lightweight design, high stability and precision, and high level of integration, the system is suitable for deployment on unmanned vehicles, ships, and sentry towers. It is particularly effective for searching and identifying small surface targets as well as near-shore targets in maritime and surrounding waters.

Equipped with an uncooled infrared thermal imager and a visible-light camera, the photoelectric turret enables all-weather detection, identification, and tracking of ground targets. It outputs real-time infrared and visible-light video feeds for mission personnel to monitor.

The photoelectric turret is widely used in a range of scenarios, including aerial and ground detection, border and coastal defense, high-altitude surveillance, and border sentry posts.

I. Photos of the actual product

Figure 1 Product Image

II. Product Functions

a) Automatic identification and tracking of typical targets.
b) Built-in self-test and fault reporting functions.
c) Visible light channel supports 20× optical zoom.
d) Equipped with both infrared and visible light detection capabilities, capable of outputting IR and visible light images.
e) Visible light features optical zoom, autofocus, manual focus, and low-light functionality.
f) Infrared sensor supports 6× optical zoom and includes a color palette switching function.
g) Integrated laser ranging function.
h) Two-degree-of-freedom movement in azimuth and pitch.
i) Multiple operating modes: automatic search, manual search, follow-up, automatic tracking, and favorites.
j) In manual search mode, capable of receiving commands from the control station and performing turret operations accordingly.
k) Carrier disturbance isolation and line-of-sight stabilization.
l) Target locking/unlocking function; when locked, the turret outputs an image with a tracking frame.
m) Automatic target tracking with resistance to natural interference.
n) Memory tracking function allows rapid target reacquisition after brief loss.
o) Adjustable gate size.
p) Tracking point switching capability.
q) Target coordinates can be calculated using laser ranging data and vehicle attitude information.
r) Target positioning function.
s) Airtight optical housing.
t) Photo and video recording functions.

III. Platform

Unmanned vehicles, shipborne equipment, sentry towers, etc.

IV. Main Technical Parameters

V. Mechanical Dimensions and Installation Interfaces

Figure 2 Product Dimensions
