MZ30TM LRF optimized 3-axis camera gimbal GPS Location Resolving 30x Optical Zoom Camera Camera Object Tracking
China Moneypro
The MZ30TM LRF is a professional-grade 3-axis camera gimbal featuring exceptional stabilization technology and advanced imaging capabilities. Equipped with a 30x optical zoom camera and Sony 1/2.8 Exmor R CMOS sensor, it delivers stunning Full HD 1080p video with precise 0.02-degree vibration control. The gimbal utilizes a mechanically limited design with concealed wiring and four damping balls for seamless, smooth footage even during high-speed flight. Advanced features include intelligent object tracking, GPS-based location resolving, and an integrated IR laser rangefinder with 5-2000 meter range capability. The system supports multiple control methods and outputs, including HDMI, IP streaming, and SDI. With working temperatures from -20 to +60 degrees Celsius and comprehensive exposure controls, this gimbal is ideal for professional surveillance, aerial cinematography, and reconnaissance applications.
The Z30TM is a highly refined 3-axis camera gimbal that delivers exceptionally accurate motor control, achieving a precision of 0.02 thanks to its dedicated processor. Unlike conventional gimbals that depend on electrical slip rings, the Z30TM features a distinctive mechanically restricted design with hidden internal wiring, which enhances both data transmission stability and long-term durability. To eliminate vibration effectively, it incorporates four damping balls along with a lightweight damping plate, resulting in consistently smooth video output.
30x Optical Zoom Camera
The Z30TM features a highly refined 3-axis camera gimbal driven by a dedicated processor, achieving motor control precision as fine as 0.01. Full 360-degree rotation is supported via the gimbal’s own movement, enabling stable and smooth footage even during high-speed flight.
Camera Object Tracking
| Hardware Parameter | |
| Working voltage | 16V |
| Input voltage | 4S ~ 6S |
| Output voltage | 5V (connect with PWM) |
| Dynamic current | 530~1300mA @ 16V |
| Working environment temp. | -20℃ ~ +60℃ |
| Output | micro HDMI(1080P 60fps) / IP (RTSP/UDP 720p/1080p 25fps/30fps) / SDI (1080P 30fps)/ Skyport |
| Local-storage | TF card (Up to 512G, class 10, FAT32) |
| Photo storage format | JPG(1920*1080) |
| Video storage format | MP4 (1080P 30fps) |
| Card reading online | SMB read / HTTP read |
| Control method | PWM / TTL / S.BUS / TCP(IP output) /DJI Pilot/UDP(IP output version) |
| Geotagging | Support, display time and GPS coordinate in picture exif |
| Gimbal Spec | |
| Mechanical Range | Pitch/Tilt: -60°～120°, Roll: ±60°, Yaw/Pan: ±300° / ±360°*N (IP output version) |
| Controllable Range | Pitch/Tilt: -45°～115°, Yaw/Pan: ±290° / ±360°*N (IP output version) |
| Vibration angle | Pitch/Roll: ±0.02°, Yaw：±0.02° |
| One-key to center | √ |
| Camera Spec | |
| Imager Sensor | SONY 1/2.8″ “Exmor R” CMOS |
| Picture quality | Full HD 1080 (1920*1080) |
| Effective pixel | 2.13MP |
| Lens optical zoom | 30x, F=4.3~129mm |
| Digital zoom | 12x (360x with optical zoom) |
| Min object distance | 10mm(wide end) to 1200mm(tele end). Default 300mm |
| Horizontal viewing angle | 1080p mode: 63.7°(wide end) ~ 2.3°(tele end) |
| Sync system | Internal |
| S/N ratio | more than 50dB |
| Min illumination | Color 0.01lux@F1.6 |
| Exposure control | Auto, Manual, Priority mode(shutter priority & iris priority), Bright, EV compensation, Slow AE |
| Gain | Auto/Manual 0dB to 50.0dB(0 to 28 steps + 2 setep/ total 15 steps) Max.Gain Limit 10.7 dB to 50.0dB (6 to 28 steps + 2 step/ total 12 steps) |
| White balance | Auto, ATW, Indoor, Outdoor, One Push WB, Manual WB, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor Auto) |
| Shutter speed | 1/1s to 1/10,000s, 22 steps |
| Backlight compensation | Yes |
| Aperture control | 16 steps |
| Defog | Yes |
| OSD | Yes |
| Camera Object Tracking | |
| Update rate of deviation pixel | 50Hz |
| Output delay of deviation pixel | 5ms |
| Minimum object contrast | 5% |
| SNR | 4 |
| Minimum object size | 32*32 pixel |
| Maximum object size | 128*128 pixel |
| Tracking speed | ±48 pixel/frame |
| Object memory time | 100 frames (4s) |
| The mean square root values of pulse noise in the object position | < 0.5 pixel |
| IR Laser Rangefinder | |
| Range | 5~2000 meters |
| Resolution | 0.5m |
| Working current: | 80mA （max） |
| Light Beam | 905nm pulse laser |
| Divergent Angle | 3 mrad |
| Laser pulse frequency | 1HZ |
| Power | ＜ 1 mW (safe for eye) |
| Ranging mode | Pulse |
| Location Resolving | Latitude and longitude of target |
| Ranefinder | Target distance measuring |
| Packing Information | |
| N.W. | 673g / 912g(Viewport Version) |
| Product meas. | 145.9*138*160mm / 146*138*165.7mm(Viewport version) |
| Accessories | 1pc gimbal camera device, screws, copper cylinders, damping balls, damping boards / Hight quality plastic box with foam cushion |
| G.W. | 3017g |
| Package meas. | 300*250*200mm |
