MTZ115TA-HNV210T625L121 Tri-axis Tri-light pod

I. Product Introduction

The MTZ115TA-HNV210T625L121 optoelectronic pod integrates an uncooled infrared thermal imager, a 10x continuous zoom visible light camera, a laser rangefinder, a three-axis servo stabilization platform, and an image processing component. It features a lightweight design, high stability and precision, strong integration, and automatic tracking capabilities. The pod is ideally suited for deployment on medium and small UAVs to perform round-the-clock reconnaissance and surveillance missions over target areas.

The pod has been adapted to several mainstream flight control platforms in China, enabling seamless integration with UAV flight control systems. It can also be connected to the ViewControlStudio display and control software platform developed by our organization, assisting system integrators in rapidly completing UAV system development.

Equipped with an uncooled infrared thermal imager and a visible light camera, the optoelectronic pod enables all-weather detection, identification, and tracking of ground targets. It outputs real-time infrared and visible light video for mission personnel to monitor.

Typical applications of the optoelectronic pod include reconnaissance, border patrol, search and rescue operations, and forest fire prevention.

II. Product Images

Figure 1 Product Image

III. Product Functions

a) Equipped with self-testing and fault reporting functions.
b) Features 10× optical zoom in the visible light band.
c) Capable of detecting both long-wave infrared and visible light bands, and outputting infrared and visible light images.
d) Visible light channel supports optical zoom, autofocus, manual focus, and low-light functionality.
e) Infrared sensor supports 1.0× to 4.0× electronic magnification and six color palette switching modes.
f) Integrated with laser ranging capability.
g) Provides three degrees of freedom (azimuth, pitch, and roll) motion.
h) Supports multiple operating modes: automatic search, manual search, follow-up, attitude stabilization, and tracking.
i) In manual search mode, can receive commands from the control station and execute gimbal operations.
j) Capable of isolating carrier disturbances and stabilizing the line of sight.
k) Supports target lock/unlock functions; when locked, the gimbal outputs an image with a tracking frame.
l) Features automatic target tracking with resistance to natural interference.
m) Includes memory tracking, enabling rapid re-acquisition of a target after brief loss.
n) Allows adjustment of the tracking gate size.
o) Supports tracking point switching.
p) Can calculate target coordinates using laser ranging data and UAV attitude information.
q) Supports bidirectional communication with the control station via RS422/TTL/100 Mbps Ethernet, outputting infrared images, visible light images, system working status, camera working status, and optical axis position.
r) Equipped with a 100 Mbps Ethernet/synchronous 422 video output interface.
s) Offers photo and video recording functions.
t) Features a quick-release mechanism.

IV. Mounting Platform

Vertical take-off fixed-wing drones, rotary-wing drones, tethered drones , etc.

V. Main Technical Parameters

model	TZ115TA-HNV210T625L121
Infrared thermal imager
Detector type	Uncooled focal plane detector
Operating band	8 m 14 m
Detector resolution	640 512
Pixel size	12 m
Lens focal length	25mm
Field of view	17.5 14㣨 5%
Pseudo-color	6 types
Numbers multiplied	1 4X
Noise equivalent temperature difference	NETD 50mK
Minimum distinguishable temperature difference	MRTD 500mK
Visible light camera
resolution	1920 1080
Response band	0.4 m to 0.9 m
Optical zoom	10 times
focal length	5.1mm to 51mm
Field of view	54 31 4.9 4.0 ( 5%)
zoom mode	Autofocus, manual focus
Minimum Illumination	0.01 Lux (Black and White)
Laser rangefinder
wavelength	905nm
Maximum ranging distance	1.2km (under conditions of visibility 15km)
Minimum ranging distance	5m
Distance measurement accuracy	1m
Ranging frequency	1Hz
Servo Platform
Orientation angle	360 n (360 continuous rotation)
Pitch angle	-115 to +90 (positive for upward)
Roll angle	-40 +40
Frame corner accuracy	0.3㣨1ң
Stable accuracy	0.1mrad (1 )
Maximum turning speed	Azimuth 50 /s, Pitch 50 /s
Maximum turning acceleration	Azimuth 20 /s2, Pitch 20 /s2
System Indicators
Image tracking	Automatically track selected target
Rated operating voltage	24VDC
Power supply voltage range	12V to 32VDC
power	Stable power consumption: 30W (peak power-on current 5A)
weight	650g (excluding quick-release parts)
volume	130mm 115mm 200mm
interface
Control Interface	RS422/ TTL/100Mbps Ethernet
Video interface	422 /100Mbps network
Storage interface	128G memory card (Mini SD card)
Image format	JPG format
Video format	AVI format
Arm type	straight arm
quick-release type	With quick release
Environmental adaptability
Operating temperature	-20+60 (-40 optional)
Storage temperature	-40 65
Vibration conditions	The acceleration is 2g; 30 minutes each in the vertical, horizontal and longitudinal directions.
Impact conditions	Peak acceleration 20g, duration 11ms
Protection level	Can fly in light to moderate rain
