MS070TA Miniature Two-Axis Tri-Light Pod

China Moneypro

a) It has self-testing and fault reporting functions;

b) It has the ability to detect long-wave infrared and visible light bands and can output infrared and visible light images simultaneously;

c) Features 7x optical hybrid zoom in visible light;

d) Possesses the ability to move freely along two axes: azimuth and pitch;

e) It has the function of receiving commands from the control station and completing pod operations;

f) It has functions such as manual search, scanning, centering, automatic tracking, and data indexing;

g) Possesses the ability to isolate carrier disturbances and stabilize the line of sight;

II. Product Functions

h) Possesses typical target (person, vehicle) recognition capabilities;

i) Features multi-target tracking capability; (optional)

j) It has a manual target locking/unlocking function;

k) It has an automatic target tracking function, which can automatically track targets and has the ability to resist natural interference;

l) It has a memory tracking function, which can recapture the target in a short time after it is briefly lost;

m) It has the function of adjusting the gate size;

n) It has a tracking point switching function;

o) It can communicate bidirectionally with the ground station via RS422/100Mbps network and output information such as infrared images, visible light images, system working status, camera working status, optical axis position, and line-of-sight angular velocity;

p) It has photo and video recording functions;

q) Equipped with manual drift correction function;

III. Mounting Platform

Miniature rotary-wing drones, fixed-wing drones, loitering munitions, etc.

IV. Main Technical Parameters

model	S070TA
Infrared thermal imager
Detector type	Uncooled focal plane detector
Lens focal length	25mm
Short-focal-length visible light camera
CMOS resolution	4 million
focal length	4.45mm
Long-range visible light camera
CMOS resolution	4 million
focal length	16mm
Hybrid zoom with long and short focal lengths	7 times
Image processing components
Automatic recognition	Capable of automatically recognizing people and vehicles with a target count of 32.
Tracking frame rate	50Hz
Image output	RTSP/UDP/RTMP are selectable, and the bitrate can be set from 100kbps to 6Mbps.
System Indicators
Power supply voltage	12V to 32VDC
interface
Control Interface	RS422/RS232/Network optional
Video interface	100M network
External plug-ins	J30-15ZKP
Image format	JPG format
Video format	AVI format
