MKIP30L30A 30x Optical Zoom + 3000m LRF Dual light Gimbal
China Moneypro
The MKIP30L30A is a professional-grade integrated gimbal system featuring 30x optical zoom capability combined with a 3000m laser range finder and dual-light technology. This compact, lightweight platform delivers exceptional stabilization through its professional 3-axis PTZ system while maintaining low power consumption. Equipped with a 2MP HD CMOS sensor and high-precision laser rangefinder, it provides superior imaging and targeting capabilities. The system supports flexible control via network and UART connectivity, enabling direct operation from ground station software. Features include local TF card storage, dual-channel video recording and photography, plus network file access. With adaptive speed control, 360-degree yaw rotation, and 1080P video output at 30fps, this gimbal is engineered for demanding surveillance, reconnaissance, and measurement applications requiring precision performance and reliability.
KIP30L30A is an integrating 270 mixed optical zoom camera,with 3000m laser range finder and professional 3-axis stabilization PTZ.This gimbal be designed with the characteristics of compact size ,light weight ,high stabilization and lower power consumption. The visible light camera adopts with 2MP HD COMS sensor and 3000m high precision LFR.Providing the ground station software ,the PTZ and camera can be directly controlled by both Network and UART,and reading the data of range finder. Supporting local TF storage and network file read and write and dual channel video recording & photography.
| Voltage | DC 12V-26.2V | Power | Dynamic 8W |
| Roll angle range | -45 +45 | Pitch angle range | -45 +120 |
| Yaw angle action range | 360 Polar rotation | Control mode | The speed is adaptive and controllable ,Support network IP and UART Serial port control |
| CMOS Size | 1/2.8 inch 200 mega pixels wide dynamic COMOS Sensor |
| Optical zoom | 30x HD optical zoom camera f=4.5 10% 135 5%mm |
| Focusing time | Real time focusing ,fast focusing time<1S |
| Video output | Network RTSP 1080P and 480P output,Video stream ,local TF card storage |
| Field Angle FOV | D : WIDE 67.8o 5% TELE 2.77o 5% H : WIDE 59.8o 5% TELE 2.34o 5% V : WIDE 40.5o 5% TELE 1.48o 5% |
| Support Mode | 1080P 30fps |
| Infrared Wavelength | 1535nm 5nm (class I safety laser) |
| measuring range | 20–3000m not allowed to illuminate bojects less than 20m |
| Accuracy/resolution | Accuracyܡ2m Ranging resolution 20m |
