MGIP335 2K Ultra-Lightweight Network Gimbal Camera
China Moneypro
The MGIP335 is a 2K ultra-lightweight network gimbal camera featuring a 4-megapixel high-definition CMOS sensor with 9x digital zoom and professional three-axis stabilization. Equipped with a Hall effect gimbal system, it delivers exceptional stability while maintaining a compact, lightweight design with minimal power consumption. The camera supports 1080P RTSP network streaming at 30fps and offers flexible control via network IP, S.BUS, or serial port connectivity. With an impressive pitch and roll jitter angle of just 0.02 degrees and horizontal jitter of 0.03 degrees, it ensures smooth, precise video capture. The device features a 3mm focal length with a 78-degree diagonal field of view, local TF card storage with H.264/H.265 compression, and one-click restore functionality. Operating on DC 3S-6S voltage with only 3W dynamic power consumption, this ultra-compact gimbal camera weighs just 60 grams and operates reliably in temperatures from -10 to +45 degrees Celsius, making it ideal for professional aerial surveillance and reconnaissance applications.
The GIP335 is a network-enabled camera that features a 9x digital zoom and a high-precision professional three-axis stabilized gimbal. The gimbal adopts a Hall effect design, offering excellent stability, compact size, lightweight construction, and low energy consumption. Its visible light camera uses a high-definition sensor with a 4-million-pixel effective resolution. The camera supports 1080P network RTSP streaming output. Control over both the camera and the gimbal can be achieved via network, serial port, or S.BUS, and the system also supports local storage through a TF card.
| Voltage | DC 3S-6s | Power | Dynamitic 3W |
| Roll angle action range | -40 +40 | Pitch angle action range | -30 ~+90 |
| Yaw angle action range | -130 ~+130 | Pitch and Roll Jitter Angle | 0.02 |
| Horizontal Jitter Angle | 0.03 | One-Click Restore | One-click restore to the initial position |
| Adjustable Gimbal ControlSpeed | Gimbal rotation is speed-adaptive based on the currentspeed mode and the visible light camera magnification | Control Methods | Supports network lP control, SBUS control, serial portcontrol(optional PWM control available) |
| SENSOR | 4-megapixel high-definition CMOS SENSOR |
| Digital Zoom | 9X digital zoom |
| Compression Storage Mode | H264,H265 video stream local TF storage |
| Network Output Mode | 1080P 30fps |
| Focal Length | 3mm |
| Field of View (FOV) | FOV:D=78 H=68 V=46 |
| Device Size | :70mm H:64mm | Work Condition | -10 to +45 /20% to 80% RH |
| Storage Condition | -20 to +60′ /20% to 95% RH | Weight (Not including dampers) | 60 10g |
