MFSD20G619 20x Optical Zoom +640*512 Thermal imaging, IP67 Waterproof Dual Light 3-Axis Stabilized IP Output Gimbal Camera

China Moneypro

The FSD20G619 is a professional-grade dual-light gimbal camera combining 20x optical zoom with 640×512 thermal imaging in an IP67 waterproof package. Featuring a high-precision three-axis stabilization system, this compact device delivers exceptional stability with minimal power consumption. The 8-megapixel visible light camera provides 1080p HD output, while the uncooled thermal imager offers 50mK sensitivity for precise temperature detection. Advanced features include dual-channel synchronous recording, picture-in-picture display modes, pseudo-color thermal switching, and intelligent human and vehicle detection tracking up to 100 simultaneous targets. Network IP control enables direct gimbal and camera operation with local TF card storage and file management. Built with aviation-grade waterproof interfaces and FOC control technology, it operates reliably across demanding environments from -10 to +45 degrees Celsius, weighing just 1120 grams.

The FSD20G619 is an integrated high-precision three-axis stabilized dual-light waterproof network gimbal, featuring a 20x optical zoom camera and a 640×512 thermal imager. This dual-light waterproof dome camera employs an aviation-grade waterproof interface and an external network IP communication interface. It adopts a high-precision encoder FOC control scheme, characterized by high stability, compact size, light weight, and low power consumption. The visible light camera uses an 8-megapixel wide dynamic range sensor, while the thermal imager features a 640×512 resolution detector with a shutterless design. It provides ground control system, supporting picture-in-picture display of dual video streams, direct network control of the gimbal and camera, local TF card storage, and network file read/write operations. It also supports dual-channel synchronous recording, multiple picture-in-picture modes, pseudo-color switching, and IP67 protection.

FSD20G619 20x Optical Zoom +640*512 Thermal imaging, IP67 Waterproof Dual Light 3-Axis Stabilized IP Output Gimbal Camera

Voltage	3S -6S 12V-26V	Power	Static 7.8W
Roll Angle	-40 ~+40	Pitch Angle	-40 ~+120
Yaw Angle	-280 ~+280	Tilt and roll direction angle jitter	0.02
Horizontal angle jitter	0.03	One-key return function	One-click automatic quick return to the initial position
PTZ control speed adjustable	When the PTZ rotates, the speed is adaptive based on the current speed mode and the multiple of the visible camera	Control mode	Support network IP control and serial port control (optional SBUS and PWM control)

CMOS Size	1 / 1.8 Inch 8 mega pixel wide dynamic range CMOS sensor
Optical Zoom	20x HD optical zoom lens, f=6.7 125 mm 5%
Focusing time	Real time focusing, fast focusing time < 1s
Video Output	Network HD RTSP output 1080p, 1080p video recording
Field Angle(FOV)	D : WIDE 66 6o 5% TELE 4.0o 5% H : WIDE 59.6o 5% TELE 3.5o 5% V : WIDE 35.7o 5% TELE 2.0o 5%
Support Mode	1080P 30fps

Resolution ratio	640 512 pixel
Space between pixels	12 m
Type	Uncooled vanadium oxide
Wavelength Range	8 14 m
Thermal sensitivity(NETD)	50mk@25 @F1.0
Field angle	19mm lens FOV 22.9 x18.4
Measurement function (optional)	Center point, maximum temp and minimum temp display; Support all area temp measurement

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	waterproof
