ME40S48G12L30 High-performance quad-light pod 40x lossless zoom + 48M fixed focus, 1280X1024 thermal imager + 3000m laser range finder

E40S48G12L30 is a high-precision professional three-axis stabilization pod with 180x hybrid zoom, 48MP fixed focus, 1280×1024 thermal imager with 25mm focal length, and 3000m laser range finder. This pod adopts a compact design with high stability, high integration, and low power consumption. The camera uses a SENSOR with an effective pixel of 48 million; 40x lossless zoom; thermal imaging uses a vanadium oxide 1280 resolution detector. 3000m high-precision ranging function. Provides software ground station, supports picture-in-picture display of dual-channel video, network, S.BUS and serial port can directly control the PTZ and camera, supports local TF storage and network file read and write operations, supports dual-channel synchronous recording, supports multiple picture-in-picture modes and pseudo-color switching.

Voltage	DC12 26.2V	Power Supply	Dynamic 10W
Roll angle range	45 45	Pitch angle range	-30 +110
Heading angle range	-285 +285	Angle jitter in pitch and roll directions	0.02
Horizontal angle jitter	0.03	One-click return to center function	One-click automatic quick return to initial position
PTZ control speed adjustable	When the gimbal rotates, the speed is adapted based on the current speed mode and the visible light camera multiple	Control method	Support network IP control, S.BUS control, serial port control (PWM control is optional)

CMOS Size	1/1.8 inch 8 megapixel wide dynamic range CMOS SENSOR
Optical zoom	20x high-definition optical zoom lens, f=6.7 125 mm 5%
Focus time	Real-time fast focus function, focusing time <1S
Video Output	Network output RTSP 1080P stream, local TF 1080P storage
Field of View FOV	D : WIDE 66.6o 5% TELE 4.0o 5%   H : WIDE 59.6o 5% TELE 3.5o 5%   V : WIDE 35.7o 5% TELE 2.0o 5%
Support Mode	1080P 30fps

CMOS Size	1/2 inch 48 million pixels
Focal length	3.5mm
Field of view	53.2*67.2

Resolution	1280×1024
Pixel spacing	12 m
Type	Uncooled vanadium oxide
Wavelength range	8 14 m
Thermal sensitivity (NETD)	50mk@F1.0@25
Field of view	25mm lens FOV 34.2 x 27.6
Measurement Functions	Support global temperature measurement, optional full pixel temperature saving function
Contrast, false color	Adjustable, multiple pseudo color modes

Infrared wavelength	1535 10nm
Measuring range	50m3000m
Accuracy/resolution	1m; resolution 40m

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization

Dimensions	208.2*144.5*176.3	Working Condition	-10 to +55 / 20% to 80% RH
Storage Environment	-20 to +60 / 20% to 95% RH	Weight	1390 20 g
