MDYDG609L12 640*512 thermal +1200-meter LRF Dual Output Mini Gimbal

China Moneypro

The MDYDG609L12 is a compact two-axis stabilized gimbal combining 640×512 thermal imaging with a 1200-meter laser rangefinder. Featuring high-precision FOC control, it delivers exceptional stability in a lightweight, low-power design. The uncooled vanadium oxide thermal sensor offers 40mK sensitivity and 9.1mm focal length for detailed thermal analysis. The integrated 905nm laser rangefinder provides 1-meter accuracy up to 1200 meters. Supporting IP and HDMI outputs with serial, S.BUS, and IP control options, it enables flexible integration. Advanced AI tracking detects and follows humans and vehicles simultaneously across up to 100 targets. With pitch range of -30 to +100 degrees and yaw of -140 to +140 degrees, plus minimal angle jitter of 0.02-0.03 degrees, precision targeting is guaranteed. Operating on 12-26.2V with just 6W dynamic power consumption, it weighs only 210g. One-click return functionality and TF card storage for images and videos complete this professional surveillance solution.

The DYDG609L12 is a high-precision two-axis stabilized camera gimbal that integrates a 640×512 thermal imaging sensor and a 1200m laser rangefinder. It supports both IP and HDMI video output. The gimbal employs a high-precision encoder FOC control scheme, offering excellent stability, compact dimensions, lightweight construction, and low power consumption. The thermal imaging module features a 640×512 vanadium oxide detector with a focal length of 9.1mm. The system supports control via serial port, S.BUS, and IP, and enables backup of images and videos to a TF card.

DYDG609L12 640*512 thermal +1200-meter LRF Dual Output Mini Gimbal

Voltage	DC 12V-26.2V	Power	Dynamic 6W
Pitch Angle Range	-30 +100	Yaw Angle Range	-140 +140
Horizontal Angle Jitter	0.03	Pitch and Roll Angle Jitter	0.02
One-click Return Function	Quick return to initial position with one click	Adjustable PTZ Speed	The current speed mode based on the multiple zoom of camera

Resolution	640*512
Pixel spacing	12 m
Type	Uncooled vanadium oxide
Wavelength range	8 14 m
Thermal sensitivity (NETD)	40mk@F1.0@25
Field of view	9.1mm Lens Field of view 48.3 38.7
Measurement function (optional)	Highest, Average, Lowest temperature display, Support global temperature measurement, optional full pixel temperature saving function

Laser wave	905nm (class 1 laser)
Detect range	5 1200m
Accuracy / Resolution	1m

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
