The MDYD415S90G635 is a compact 2-axis gimbal camera system featuring dual visible light cameras with 8MP and 2MP sensors, plus a 640×512 thermal imaging module. This lightweight, low-power stabilization pod delivers exceptional performance with minimal jitter angles of 0.02 to 0.03 degrees. It supports network RTSP streaming with picture-in-picture output modes, dual-channel TF card recording, and 9x digital zoom. The system offers flexible control via serial port, network, or S.BUS, with adjustable gimbal speeds and one-click restore functionality. Operating on 12-26.2V DC with just 6.6W power consumption, it combines high stability with portability. Advanced features include AI-powered human and vehicle detection tracking up to 100 simultaneous targets, global temperature measurement, and H.264/H.265 video compression for 4K storage. Perfect for surveillance, reconnaissance, and thermal monitoring applications.
The DDYD415S90G635 is a compact, three-sensor, two-axis stabilization gimbal integrating two visible-light cameras (8 MP and 2 MP) along with a 35mm focal length 640×512 thermal imaging module. Designed for high stability, the system features a lightweight, small-footprint, low-power architecture. It supports RTSP network streaming, with three video channels capable of picture-in-picture (PiP) output in multiple layout modes. Dual-channel synchronized video recording and photo capture to a local TF card are supported. Control over the camera and gimbal functions is enabled via serial port, network, or S.BUS, with up to 9x digital zoom. The visible cameras offer focal lengths of 35mm and 6mm respectively.
Voltage
DC 12V-26 .2V
Power
Dynamic 6.6w
Yaw Angle
-20 +180
Pitch Angle
360
Pitch and Roll Jitter Angle
0.02
Horizontal Jitter Angle
0.03
One-Click Restore
One-click restore to the initial position
Adjustable Gimbal Speed
When the gimbal rotates, the speed is adapted based on the current speed mode the visible light camera multiple
CMOS Size
CMOS SENSOR 8MP
Dogital zoom
Suport 7x digital zoom
Compressed storage mode
H264 H265,Video streaming local TF card storage 4K
Field Angle FOV
35mm focal-length, FOV 10.1 x 7.6
CMOS Size
CMOS SENSOR 2MP
Dogital zoom
Suport 9x digital zoom
Compressed storage mode
H264 Video streaming local TF card storage 4K
Field Angle FOV
6mm focal-length FOV 60 x 43
Resolution
640 512 pixel
Pixel spacing
12 m
Type
Uncooled vanadium oxide
Wavelength range
8 14 m
Thermal sensitivity (NETD)
50mk@25 @F1.0
Field of view
35mm focal-length FOV:12.5 x10
Global temperature measurement
Support global temperature measurement, optional full-pixel temperature saving function
