MDYD30G619 High Performance Dual Sensor Gimbal 30X Optical Zoom+19mm 640*512 IR

The MDYD30G619 is a professional dual-sensor stabilization gimbal combining a 30X optical zoom CMOS camera with a 640×512 thermal imaging sensor. Featuring a full metal construction and high-precision FOC control, this compact system delivers exceptional stability with minimal power consumption. The 2-megapixel visible light sensor offers wide dynamic range, while the uncooled vanadium oxide thermal sensor provides 50mK sensitivity. Supporting RTSP streaming, 4 Picture-in-Picture modes, and 10 pseudo-color thermal modes, it enables comprehensive surveillance capabilities. Advanced AI tracking detects and follows humans and vehicles simultaneously. Control options include network, serial port, and S.BUS connectivity, with local TF card storage. Operating from DC12-26.2V at just 7.5W dynamic power, the gimbal achieves 0.03-degree horizontal stability and 360-degree continuous yaw rotation. Ideal for professional security, reconnaissance, and monitoring applications.

Featuring a rugged all-metal housing, the DYD30G619 is a compact dual-sensor gimbal camera designed for high-precision stabilization. It integrates a daytime CMOS module capable of 270x hybrid zoom (2MP effective pixels, wide dynamic range) and a 19mm thermal imaging lens paired with a 640×512 vanadium oxide detector equipped with a shutter mechanism. The gimbal utilizes an FOC control architecture with high-resolution encoders, delivering outstanding stability in a lightweight, energy-efficient, and space-saving form factor.

The camera supports Ethernet RTSP streaming output, and allows full control of both the gimbal and camera functions via network, serial port, or S.BUS. Onboard features include 4 Picture-in-Picture display layouts, 10 pseudo-color palettes for thermal imaging, and local recording to a TF card.

DYD30G619 High Performance Dual Sensor Gimbal 30X Optical Zoom+19mm 640*512 IR

Voltage	DC12 26.2V	Power	Dynamic 7.5W
Pitch Angle	-30 +120	Yaw Angle	360 *N
Horizontal angle jitter	0.03	Tilt and roll direction angle jitter	0.02
One-Click Restore	One-click to center	Adjustable Gimbal Speed	When the gimbal rotates, the speed is adapted based on the current speed mode and the visible light camera multiple

CMOS Size	1/2.8 INCH 2 mega pixel wide dynamic CMOS SENSOR
Optical Zoom	30x HD optical zoom lens, f=4.5 10% 135 10%mm
AF Time	Real time fast focusing, focusing time < 1s
Video Output	Network output RTSP 1080P stream, 1080P local TF card storage
Field Angle(FOV)	D : WIDE 67.8o 5% TELE 2.77o 5% H : WIDE 59.8o 5% TELE 2.34o 5% V : WIDE 40.5o 5% TELE 1.48o 5%
Support Mode	1080P 30fps

Resolution ratio	640 512pixel
Space between pixels	12 m
Type	Uncooled vanadium oxide
Wavelength Range	8 14 m
Thermal sensitivity(NETD)	50mk@25 @F1.0
Video Output	IP Output
Field of view	19mmLens Field of view 22.9 x18.4
Measurement function (optional)	Highest, Average, Lowest temperature display, Support global temperature measurement, optional full pixel temperature saving function

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
