MDIY10S90 10x Optical zoom IRCUT 3-Axis Gimbal, IP output

China Moneypro

The MDIY10S90 is a professional-grade drone gimbal system featuring 90x mixed zoom capability with 3-axis stabilization and IP output connectivity. Equipped with a 10x optical zoom lens and 2-megapixel CMOS sensor, it delivers 1080P RTSP network streaming and local TF card storage. The gimbal utilizes high-precision FOC encoder control for exceptional stability with minimal jitter angles of 0.02 degrees pitch/roll and 0.03 degrees horizontal. Its compact design weighs just 425 grams while operating on DC12V-26.2V with only 5W dynamic power consumption. The system supports dual control via UART and IP protocols, features one-click position restoration, and includes advanced human and vehicle detection tracking up to 100 simultaneous targets. With wide operational temperature range and robust construction, this gimbal delivers professional surveillance and monitoring capabilities in a lightweight, efficient package.

The DIY10S90 is a drone-mounted gimbal camera system that integrates a 90x hybrid zoom lens with a 3-axis stabilized pan-tilt head. It features IP-based output and adopts a high-precision encoder FOC control scheme, offering excellent stability, compact size, light weight, and low power consumption. The camera utilizes a 2-megapixel effective CMOS sensor and supports 1080P network RTSP streaming output. Both the camera and the gimbal can be controlled via UART or IP interface, and local TF card storage is supported.

DIY10S90 10x Optical zoom IRCUT 3-Axis Gimbal, IP output

Voltage	DC12V-26.2V	Power	Dynamic 5W
Roll angle action range	-45 +45	Pitch angle action range	-45 +120
Yaw angle action range	-285 +285	Pitch and Roll Jitter Angle	0.02
Horizontal Jitter Angle	0.03	One-Click Restore	One-click restore to the initial position

SENSOR	1/2.8 inch 2 mega pixels wide dynamic CMOS SENSOR
Optical Zoom	10x HD optical zoom lens, f=5.15 5% 47.38 5%mm
AF Time	Real time fast focusing, focusing time < 1s
Video Output	RTSP stream IP network output, 1080P video stream local TF card storage
Local Record	photos and videos storage on local TF card; 1080P video stream real-time output
Field Angle (FOV)	D : WIDE 69.5o 5% TELE 7.95o 5% H : WIDE 61.5o 5% TELE 7.00o 5% V : WIDE 35.0o 5% TELE 3.97o 5%
Support Mode	1080P 30fps

Device Size	:150mm H:140mm	Work Condition	-10 to +50 / 20% to 80% RH
Storage Condition	-20 to +60 / 20% to 95% RH	Weight (Not including dampers)	425 10g

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
