MDIY10N800 90x Hybrid zoom +850nm infrared laser illumination Ethernet Output Small Gimbal

China Moneypro

The MDIY10N800 is a professional-grade dual-system gimbal combining a 90x hybrid zoom daytime camera, 850nm infrared laser illumination, and a high-precision three-axis stabilized gimbal. Featuring a 2-megapixel wide dynamic CMOS sensor with 10x optical zoom and real-time fast focusing under 1 second, it delivers 1080P 30fps video via Ethernet RTSP output. The gimbal employs advanced FOC control with exceptional stability, minimal jitter of 0.02 degrees pitch/roll and 0.03 degrees horizontal, and supports multiple control modes including IP, UART, and S.BUS commands. Compact and lightweight at 590g, it operates on DC12V-26.2V with just 16W dynamic power consumption. The integrated AI tracking system detects and tracks humans and vehicles simultaneously, supporting up to 100 targets with dynamic stabilization. Perfect for surveillance, reconnaissance, and professional monitoring applications requiring precision, reliability, and extended operational range.

DIY10N800 is a dual system integrating a 90x mixed zoom daytime sensor, an 850nm infrared laser illumination module and a high-precision professional three-axis stabilized gimbal. It adopts ethernet RTSP output and ethernet control. The gimbal adopts high-precision encoder FOC control scheme and has the characteristics of high stability, small size, light weight and low power consumption. The visible light camera uses a wide dynamic SENSOR with an effective pixel of 2 million. Ethernet and serial port as well as S.BUS can control the camera and gimbal, and it supports local TF card storage. DIY10N800 90x Hybrid zoom +850nm infrared laser illumination Ethernet Output Small Gimbal

DIY10N800 90x Hybrid zoom +850nm infrared laser illumination Ethernet Output Small Gimbal

Voltage	DC12V-26.2V	Power	Dynamic 16W
Roll Angle action range	-45 +45	Pitch action range	-30 +95
Yaw angle action range	-295 +295	Angle jitter in pitch and roll direction	0.02
Horizontal Angle jitter	0.03	One-click return function	Quick return to initial position with one click
Adjustable Gimbal Speed	When the gimbal rotates, speed adaptation is based on the current speed mode and visible light camera magnification	Control mode	IP and UART command control, SBUS control (PWM control optional )

CMOS Size	1/2.8 inch 2M Pixels Wide CMOS SENSOR
Optical zoom	10 x HD optical zoom lens, f=5.15 5% 47.38 5%mm
Focus time	Real-time fast focusing function, focusing time <1S
Video Output	Ethernet RTSP video output at 1080P and record video data on local TF card
Field Angle(FOV)	D : WIDE 69.5o 5% TELE 7.95o 5% H : WIDE 61.5o 5% TELE 7.00o 5% V : WIDE 35.0o 5% TELE 3.97o 5%
Support Mode	1080P 30fps

Central Wavelength	850nm 8nm
Minimum Emission Angle	2 0.2
Maximum Emission Angle	52 2

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
