MDIY10L12 90x Hybrid zoom + 1200m ranging dual output small

China Moneypro

The MDIY10L12 is a professional-grade dual-output imaging system featuring 90x hybrid zoom capability and 1200-meter laser ranging precision. This compact, lightweight stabilization pod integrates a 2-megapixel wide dynamic sensor with advanced three-axis FOC control for exceptional stability. Equipped with 10x optical zoom and real-time fast focusing under 1 second, it delivers 1080P HD RTSP network output with dual-channel local TF storage. The system supports multiple control modes including Network, IP, S.BUS, and PWM, with adjustable PTZ speeds and one-click return functionality. Advanced AI tracking detects and follows humans and vehicles simultaneously with dynamic stabilization. Operating on DC 12V-26.2V with minimal 6W power consumption, it features precise 0.02-degree pitch and roll jitter control. Ideal for surveillance, reconnaissance, and professional monitoring applications requiring extended range and reliable performance in demanding environments.

DIY10L12 is a zoom dual-optical integrated system integrating 90 times hybrid zoom, 1200-meter laser ranging module, and high-precision professional three-axis stabilization pod. It uses network IP, HDMI dual output, IP control, and the pan/tilt adopts high-precision The encoder FOC control scheme has the characteristics of high stability, small size, light weight and low power consumption; the visible light camera uses a wide dynamic SENSOR with 2 million effective pixels. Serial port , S.BUS and network can control the camera and PTZ, and support local TF dual-channel video and photo taking. DIY10L12 90x Hybrid zoom + 1200m ranging dual output small

DIY10L12 90x Hybrid zoom + 1200m ranging dual output small

Voltage	DC 12V-26.2V	Power	Dynamic 6W
Roll Angle action range	-45 +45	Pitch action range	-30 +95
Yaw angle action range	-295 +295	Pitch and Roll Jitter Angle	0.02
Horizontal jitter Angle	0.03	One-click return function	One-click to return to the initial position
PTZ Speed adjustable	When the gimbal rotates, it performs speed adaptation based on the current speed mode and visible light camera multiple	Control mode	Support Network,IP ,Network Sbus control PWM optional

CMOS Size	1/2.8inch 200MP Effective pixels CMOS SENSOR
Optical zoom	10x HD Optical zoom lens f=5.15 5% 47.38 5%mm
Focus time	Real-time fast focusing function,focusing time<1S
Video Output	Network HD RTSP output 1080P,Video stream local TF storage
Field Angle(FOV)	D : WIDE 69.5o 5% TELE 7.95o 5% H : WIDE 61.5o 5% TELE 7.00o 5% V : WIDE 35.0o 5% TELE 3.97o 5%

Infrared Wavelength	905nm (class 1 laser)
Measuring range	5 1200m
Accuracy	1m

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
