MDIY10G619-E 10x optical zoom +640 thermal imaging IP output

China Moneypro

The MDIY10G619-E is a professional drone gimbal payload combining 90x hybrid zoom with dual imaging capabilities. It features a 2MP EO camera with 10x optical zoom and a 640×512 thermal imaging camera with 19mm lens for comprehensive surveillance. The system delivers 1080P IP output via Ethernet with local TF storage support. Its 3-axis stabilized PTZ offers exceptional precision with minimal jitter and full 360-degree yaw rotation. The uncooled vanadium oxide thermal sensor provides 50mK sensitivity for accurate temperature detection. Advanced features include picture-in-picture modes, pseudo-color switching, and intelligent tracking for up to 100 human and vehicle targets simultaneously. Operating on DC12-26.2V with just 6.5W dynamic power consumption, this compact 525g payload excels in security, surveillance, and reconnaissance applications with synchronized UART and IP control.

The DIY10G619 is a drone-mounted gimbal payload that combines a 90x hybrid zoom EO camera (2MP) with a 19mm lens 640×512 IR thermal imager, all stabilized by a 3-axis PTZ unit. Data output is via Ethernet. The electro-optical camera features a wide dynamic sensor delivering 2 million effective pixels, while the infrared module utilizes a 640×512 vanadium oxide detector with a built-in baffle mechanism. This system supports picture-in-picture display and multiple pseudo-color palettes. Both UART and IP interfaces enable synchronized control of the camera and gimbal, and local storage on a TF card is available.

DIY10G619-E 10x optical zoom +640 thermal imaging IP output

Voltage	DC12 26.2V	Power	Dynamic 6.5W
Roll Angle	-45 +45	Pitch Angle	-30 +100
Yaw Angle	-285 +285	Tilt and roll direction angle jitter	0.02
Horizontal angle jitter	0.03	One-Click Restore	One-click restore to the initial position

CMOS Size	1/2.8 inch2 mega effective pixels CMOS SENSOR
Optical Zoom	10x HD optical zoom lens, f=5.15 5% 47.38 5%mm
AF Time	Real time fast focusing, focusing time < 1s
Video Output	IP HD RTSP output 1080P, video stream local TF storage
Field Angle(FOV)	D : WIDE 69.5o 5% TELE 7.95o 5% H : WIDE 61.5o 5% TELE 7.00o 5% V : WIDE 35.0o 5% TELE3.97o 5%
Support Mode	1080P 30fps

Resolution ratio	640 512 pixel
Space between pixels	12 m
Type	Uncooled vanadium oxide
Wavelength Range	8 14 m
Thermal sensitivity(NETD)	50mk@25 @F1.0
Contrast, pseudo color	Adjustable, multiple pseudo color modes
Measurement function (optional)	Center point, Lowest and Highest temperature display; Support global temperature measurement
Field angle	19mm lens FOV 22.9 18.4

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Gyroscope stabilization
