MDIY10G619 10x optical zoom +640 thermal imaging IP output

China Moneypro

The MDIY10G619 is an advanced drone gimbal payload combining 90x hybrid zoom with dual imaging capabilities. It features a 2MP EO camera with 19mm lens and a 640×512 thermal IR camera, both mounted on a 3-axis stabilized PTZ system. The EO camera utilizes wide dynamic range sensor technology for superior image quality, while the IR camera employs uncooled vanadium oxide detector technology with baffle design for precise thermal imaging. The system delivers 1080P IP output via Ethernet with local TF storage support. It offers picture-in-picture modes and pseudo-color switching for enhanced analysis. Dual UART and IP control enables synchronized camera and PTZ operation. With minimal angle jitter and one-click restore functionality, this compact 525g payload operates on DC12-26.2V power and excels in surveillance, inspection, and thermal monitoring applications.

DIY10G619 is a drone gimbal payload which integrating 90x Hybrid zoom, 2MP EO camera, with 19mm lens 640×512 IR camera, and 3-axis stabilized PTZ. It adopts Ethernet output. The EO camera uses a wide dynamic sensor with 2 mega effective pixels; The IR camera adopts 640×512 resolution vanadium oxide detector with baffle design. The system supports picture-in-picture modes, pseudo-color switching. The UART and IP can synchronously control the camera and PTZ, and support local TF storage.

DIY10G619 10x optical zoom +640 thermal imaging IP output

Voltage	DC12 26.2V	Power	Dynamic 6.5W
Roll Angle	-45 +45	Pitch Angle	-30 +100
Yaw Angle	-285 +285	Tilt and roll direction angle jitter	0.02
Horizontal angle jitter	0.03	One-Click Restore	One-click restore to the initial position

CMOS Size	1/2.8 inch2 mega effective pixels CMOS SENSOR
Optical Zoom	10x HD optical zoom lens, f=5.15 5% 47.38 5%mm
AF Time	Real time fast focusing, focusing time < 1s
Video Output	IP HD RTSP output 1080P, video stream local TF storage
Field Angle(FOV)	D : WIDE 69.5o 5% TELE 7.95o 5% H : WIDE 61.5o 5% TELE 7.00o 5% V : WIDE 35.0o 5% TELE3.97o 5%
Support Mode	1080P 30fps

Resolution ratio	640 512 pixel
Space between pixels	12 m
Type	Uncooled vanadium oxide
Wavelength Range	8 14 m
Thermal sensitivity(NETD)	50mk@25 @F1.0
Contrast, pseudo color	Adjustable, multiple pseudo color modes
Measurement function (optional)	Center point, Lowest and Highest temperature display; Support global temperature measurement
Field angle	19mm lens FOV 22.9 18.4

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
