MDIP290G650 1080P visible light + 50mm lens 640x512 thermal imaging + Dual Sensor Camera with 3-axis Gimbal

MDIP290G650 1080P visible light + 50mm lens 640×512 thermal imaging + Dual Sensor Camera with 3-axis Gimbal

China Moneypro

The MDIP290G650 is a professional dual-sensor gimbal camera system combining 1080P visible light imaging with 640×512 thermal imaging via a 50mm lens. Featuring a high-precision 3-axis stabilized PTZ with FOC control, it delivers exceptional stability in a compact, lightweight design with minimal power consumption. The visible light camera uses a 2-megapixel low-illumination CMOS sensor, while the thermal imaging employs an uncooled vanadium oxide detector with baffle design for superior performance. Supporting network RTSP streaming, picture-in-picture modes, and multiple pseudo-color options, this system offers versatile control via SBUS, UART, UDP, and PWM protocols. With local TF storage capability and full-metal construction, it’s engineered for demanding professional applications requiring reliable dual-sensor surveillance and thermal analysis.

The DIP290G650 is a dual-sensor gimbal camera system for drones, combining a fixed-focus 1080P visible-light sensor with a 50mm lens and a 640×512 thermal imaging sensor. It features a high-precision professional three-axis stabilized gimbal with encoder-based FOC control, offering excellent stability, compact size, lightweight construction, and low power consumption. The visible light camera is built around a low-illumination 2MP CMOS sensor, while the thermal module uses an uncooled vanadium oxide detector with a resolution of 640×512 and includes a built-in baffle design. The system supports network RTSP streaming, multiple picture-in-picture display modes, and various pseudo-color palettes. Control is available through SBUS, UART, UDP, or PWM protocols. It also includes a microSD card slot for local recording and comes in a full-metal enclosure.

DIP290G650 1080P visible light + 50mm lens 640x512 thermal imaging + Dual Sensor Camera with 3-axis Gimbal

Voltage	DC12 26.2V	Power	Dynamic 6W
Roll Angle	-45 +45	Pitch Angle	-30 +100
Yaw Angle	-280 +280	Tilt and roll direction angle jitter	0.02
Horizontal angle jitter	0.03	One-Click Restore	One-click restore to the initial position

CMOS Size	CMOS SENSOR pixel: 2 million pixels
Digital zoom	9x Digital Zoom
Focus time	Real time focusing, fast focusing time < 1s
Video Output	IP output RTSP 1080P /480P video stream, local TF1080P storage
Field Angle(FOV)	60 43
Support Mode	1080P 30fps

Resolution ratio	640 512 pixel
Space between pixels	12 m
Type	Uncooled vanadium oxide
Wavelength Range	8 14 m
Thermal sensitivity(NETD)	50mk@25 @F1.0
Contrast, pseudo color	Adjustable, multiple pseudo color modes
Measurement function (optional)	Supports global temperature measurement, optional full-pixel temperature recording function
Field angle	50mm lens FOV D 11.23㡢H 8.78㡢V 7.03

Min tracking target size	16 16 pixels	Max tracking target size	256 256 pixels
Target Memory Time	2 seconds	Tracking speed	50 Pixel/Frame max
Simultaneous detection qty	100 targets max	Recognized categories	Human and Vehicle
Min detection target size	32 32 pixels	Debounce	Dynamic stabilization
