MAT61 Motorized Focusing Thermal Camera
China Moneypro
AT61 is a high-performance and high-precision electrically adjustable temperature measurement thermal imager that uses a uncooled focal plane detector and offers multiple lens options.
Supporting multiple protocols such as RTSP and Onvif, equipped with professional application software and universal SDK development package.
It is ideal choice for fields such as electronic circuits, education and research, and industrial automation.
Feature
High-quality image output
AT31 can accurately transmit on-site temperature data. Its electric focusing lens design enables the observations of multiple depth-of-field targets using the same lens, thus providing more accurate temperature measurements.
The device can output high-quality infrared images with a resolution of 384 288, supporting rapid temperature data analysis and determination.
The device can output high-quality infrared images with a resolution of 384 288, supporting rapid temperature data analysis and determination.
High-speed Frame Rate and Real-time Data Transmission
With an image and temperature frame rate of up to 50Hz, AT31 can capture temperature changes at a very high speed. It is very suitable for applications requiring real-time monitoring of temperature changes.
Equipped with a Gigabit network interface, the device also supports real-time transmission of on-site status temperature data, allowing for image monitoring and temperature data analysis at anytime.
Equipped with a Gigabit network interface, the device also supports real-time transmission of on-site status temperature data, allowing for image monitoring and temperature data analysis at anytime.
Wide Measurement Range and Temperature Compensation Algorithm
With a wide measurement range from -20 C to +550 C, AT31 is suitable for industrial scenarios with various high-temperature requirements. The device utilizes a temperature compensation algorithm to adjust for environmental factors and ensure measurement accuracy and reliability
Specification
| Thermal Imaging Parameters | |
| Detector | Uncooled VOx detector |
| Infrared Resolution | 640 512 |
| Pixel pitch | 12 m |
| Spectral Band | 8 m~14 m |
| Thermal Sensitivity (NETD) | <50mK |
| Temperature Measurement Function | |
| Measurement Range | -20 ~+150 ,0 ~550 |
| Measurement Accuracy | 2 C or 2% of readings, whichever is greater. |
| Temperature Measurement Correction | Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance |
| Measurement Tool | Settings of measurement rules for a total of 12 points, lines, and areas Supports isotherm setting |
| Temperature Width Stretch | Support temperature width stretch |
| Image and Video | |
| Frame Rate | 25 Hz |
| Palettes | 18 color palettes including black-hot, white-hot, iron red, rainbow, etc. |
| Video Standards | H.264, H.265 |
| Thermal Image Capture | Support thermal image capture and secondary analysis |
| Mirror Image | Horizontal/Vertical/Diagonal |
| Digital Zoom | 1.0~8.0 continuous zoom (step size: 0.1) |
| System Interface | |
| Communication interface | RJ45 supporting Gigabit network and customized RS485 for Pecol-D protocol. |
| Alarm Interface | 1-channel alarm output (optional) |
| Video Interface | 1-channel analog video |
| Network Protocol | TCP, UDP, ICMP, DHCP, RTSP |
| Interface Protocol | ONVIF, GB28181 |
| Device Specifications | |
| Operating Temperature | -20 ~+60 |
| Power supply mode | 10~36V DC, POE |
| Typical Power Consumption | 3.3W |
| Dimensions | 56mm 51mm 119mm |
| Weight | About 430g |
| Operating Temperature | -20 ~+60 |
| Power supply mode | 12V DC or PoE power supply |
| Typical Power Consumption | <2.5W |
| Dimensions | <50x50x90mm |
| Weight | About 200g |
| Battery Charging Time | About 3h |
| Battery Operating Time | About 3h |
| Cloud Services | Transfer shooting data to a cloud drive, share data and perform secondary analysis at multiple clients; support automatic time synchronization |
| Power Management | Automatic shutdown: 5 minutes, 10 minutes, 20 minutes, never |
| Measurement and Analysis | |
| Laser Pointer | Available |
| System Functions | |
| Temperature Alarm | Available |
| Others | |
| Analysis Software | PC & App |
| Tripod Support | Available |
| Operating Temperature | -10 C~+50 C |
| Storage Temperature | -20 C~+60 C |
| Relative Humidity | 10%~95%, non-condensing |
| Drop Protection | 2m |
| Ingress Protection Rating | IP54(IEC 60529) |
| Shock and Vibration | Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6) |
| Dimensions | 258.4 105.1 102.3(mm) |
| Weight | About 670g |
| Certificaitons | CE/ROHS, etc. |
| Packing List | 5V 3A power adaptor, USB cable, SD card, battery 2, Quick Start Guide, battery charger, calibration certificate, package list |
Application Scenariosa
Power Monitoring
Industrial Manufacturing
Machine Vision
Fire Monitoring
