MAT31 Motorized Focusing Thermal Camera

China Moneypro

MAT31 is a high-performance and high-precision electrically adjustable temperature measurement thermal imager that uses a uncooled focal plane detector and offers multiple lens options.

Supporting multiple protocols such as RTSP and ONVIF, equipped with professional application software and universal SDK development package.

It is ideal choices for fields such as electronic circuits, education and research, and industrial automation.

Feature

High-quality image output

AT31 can accurately transmit on-site temperature data. Its electric focusing lens design enables the observations of multiple depth-of-field targets using the same lens, thus providing more accurate temperature measurements.
The device can output high-quality infrared images with a resolution of 384 288, supporting rapid temperature data analysis and determination.

High-speed Frame Rate and Real-time Data Transmission

With an image and temperature frame rate of up to 50Hz, AT31 can capture temperature changes at a very high speed. It is very suitable for applications requiring real-time monitoring of temperature changes.
Equipped with a Gigabit network interface, the device also supports real-time transmission of on-site status temperature data, allowing for image monitoring and temperature data analysis at anytime.

Wide Measurement Range and Temperature Compensation Algorithm

With a wide measurement range from -20 C to +550 C, AT31 is suitable for industrial scenarios with various high-temperature requirements. The device utilizes a temperature compensation algorithm to adjust for environmental factors and ensure measurement accuracy and reliability

Specification

Thermal Module
Detector Type	VOx, uncooled FPA detectors
Spectral Range	8~14 m
NETD	40mK(@25 C, F#1.0, 25 Hz)
Resolution	640 512
Pixel Pitch	12 m
Focal Length	13mm/25mm
Optical Module
Sensor	4MP 1/1.8″ Progressive Scan CMOS
Resolution	2688 1520
Focal Length	6.5~130mm, 20x
Image Function
Picture in Picture	Support
PTZ
Pan	360 continuous 0.1 ~100 /s
Tilt	-90 ~+90㣬0.1 ~60 /s
Preset	256
Scan mode	Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan
Wiper	wiper
Temperature Measurement
Temperature Range	-20 ~+550
Temperature Accuracy	2 or 2%
Temperature Measurement	Support 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire Detection	Support
VCA	Support Line Crossing&Intrusion detection
2-Way Audio	Support
Linkage Action	Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power	DC 12V 25%
Network	1 RJ45 10M / 100M self-adaptive Ethernet port
Audio	1 in/1 out
Alarm	2 in/2 out
Storage	Micro SD memory maximum 256G
Reset	Support
Serial Port	1 channel RS485, can support Pelco protocol
General
Work Environment	-40 ~+70棻<90%RH
Protection	IP66
Power Consumption	max. 30w
Dimenstion(mm)	358 166 203
Weight	5kg
